In the area of training, PLC-Lab can provide each student with their own system for the program test. The programmer can concentrate fully on testing the program.Įven "peripheral areas" of a system, which in reality are difficult to bring about, can be carried out in PLC-Lab in order to test the program behavior at these "extreme points". Things such as sensor behavior (normally open/ normally closed) are set once and then no longer need to be observed.
You can run a test with PLC-Lab much more extensively, since the system behavior does not have to be brought about "manually". Such a preliminary commissioning saves time and money. A test can also take place even if the hardware is not yet available. In this way, a PLC program or a GRAFCET can be tested without damaging the hardware. In industry, PLC-Lab enables the safe and convenient simulation of entire projects or individual project components. PLC-Lab can be used in both industry and training. Use of PLC-Lab is based on programs such as PowerPoint by Microsoft. The setup of a system or test environment is straightforward. The user interface is also displayed razor sharp on high-resolution screens (e.g. This means that the objects in PLC-Lab can be enlarged or reduced in size without any loss of quality. The user interface and the drawing area of PLC-Lab are entirely vector-oriented. If you want to simulate the behaviour of a real plant in PLC-Lab, you can now achieve this with the help of the physical possibilities of PLC-Lab and additionally algorithmically, with the help of the powerful C# programming language. An integrated physics engine ensures the realistic simulation of the objects.įrom version 2 of PLC-Lab, a C# script is supported.
In addition, you can set parameters such as density, surface friction and elasticity. For example, objects can be depend on gravity and be magnetic. The objects can be assigned physical properties, which then influence the behavior of the objects during simulation. The objects in PLC-Lab offer extensive design and setting options, so the variety of project types that can be implemented with PLC-Lab is very high: With PLC-Lab, virtual test environments or systems can be created and then used for testing PLC programs or GRAFCETs. Tutorial CodeSys V3 controller via OPC UA
